The system can simulate the process of grounding system, so that students can have a preliminary intuitive understanding of the grounding system, and be familiar with the composition, connection and operation principle of the grounding system.

Features:

The experimental circuit and devices are fully configured and can be used in combination to complete the training contents of a variety of subjects.

The training platform has a good security system.

Training platform adopts aluminum frame type structure, measuring instrument and load module uses the way of hanging box installation, training power built-in integrated installation, each unit with flexible, easy to use, not easy to damage.

Technical data:

Power box unit: aluminum profile panel structure, embedded installation of power parts, instrument and load module with aluminum alloy hanging box unit form, connection convenience

Ground training device: all aluminum alloy structure, the shape dimension 800 * 800 * 1580mm (long width).
